Picotig-series

Picotig 220 puls DC – The casing

Reimagined, down to the smallest detail.

Wherever your welding work may lead you, the Picotig 220 puls is the perfect companion and a true powerhouse. Its rugged casing stands up to even the biggest challenges and offers you a wide variety of different expansion options thanks to a host of accessories. This enables you to precisely and individually adapt your Picotig to your requirements so it does just what you need it to do.

The TIG compact class 220 puls

Sophisticated solutions combined in a single powerful machine. The Picotig 220 puls scores across the board, including with its integrated wear parts box in the handle and its practical cable holder to make your work even more convenient. What’s more, thanks to its increased efficiency and standby function, the power pack saves both electricity and costs. The protective cap provided as standard effectively protects the control against water, dirt and impact. All this makes the Picotig 220 puls the perfect machine for the workshop and the construction site.


EWM warranty logo
EWM Industry 4.0
EWM allin
blue evolutions logo
Picotig 220
  • Picotig 220 puls DC
  • Picotig 200 MV puls TG
  • Picotig 200 puls AC/DC 5P TG
  • Picotig 200 puls AC/DC 8P TG
  • Overview
  • Technical data of the Picotig 220 puls DC

    VersionPicotig 220 puls DC 5P
    Setting range for welding current5 A - 220 A
    Setting range for welding current @ 110 V - 120 V5 A - 170 A
    Duty cycle 40 °C220 A / 40 %
    190 A / 60 %
    160 A / 100 %
    Duty cycle @ 110 V - 120 V170 A / 40 %
    150 A / 60 %
    120 A / 100 %
    Open circuit voltage97 V
    Mains voltage (ex works)1 x 230 V
    Mains voltage (possible)1 x 110 V - 120 V
    Mains tolerances (ex works)-40 % up to +15 %
    Mains tolerances (ex works) @ 110 V - 120 V-15 % up to +15 %
    Mains frequency50 Hz / 60 Hz
    Recommended generator power6.6 kVA
    Recommended generator power @ 110 V - 120 V4.6 kVA
    Efficiency84 %
    Power consumption Pi10 W
    Protection classificationIP23
    Test mark
    EMC classA
    Dimensions (L x B x H)454 mm x 165 mm x 321 mm
    17.9 inch x 6.5 inch x 12.6 inch
    Weight10 kg / 22.1 lbs
    StandardsIEC 60974-1, -3 and -10 CL.A
  • Technical data of the Picotig 200 MV puls TG

    VersionPicotig 200 MV puls TG
    Setting range for welding current5 A - 200 A
    Setting range for welding current @ 115 V5 A - 150 A
    Duty cycle 40 °C200 A / 25 %
    150 A / 60 %
    140 A / 100 %
    Duty cycle @ 115 V150 A / 35 %
    120 A / 60 %
    100 A / 100 %
    Open circuit voltage90 V
    Mains voltage (ex works)1 x 230 V
    Mains voltage (possible)1 x 115 V
    Mains tolerances (ex works)-40 % up to +15 %
    Mains tolerances (ex works) @ 115 V-15 % up to +15 %
    Mains frequency50 Hz / 60 Hz
    Recommended generator power8.1 kVA
    Recommended generator power @ 115 V5.5 kVA
    Efficiency86 %
    Power consumption Pi17 W
    Protection classificationIP23
    Test mark
    EMC classA
    Dimensions (L x B x H)428 mm x 181 mm x 294 mm
    16.9 inch x 7.1 inch x 11.6 inch
    Weight9.8 kg
    StandardsIEC 60974-1, -3 and -10 CL.A
  • Technical data of the Picotig 200 puls AC/DC 5P TG

    VersionPicotig 200
    Setting range for welding current3 A - 200 A
    Duty cycle 40 °C200 A / 35 %
    150 A / 60 %
    140 A / 100 %
    Open circuit voltage43 V
    Mains voltage (ex works)1 x 230 V
    Mains tolerances (ex works)-40 % up to +15 %
    Mains frequency50 Hz / 60 Hz
    Recommended generator power8.1 kVA
    Efficiency85 %
    Power consumption Pi24 W
    Protection classificationIP23
    Test mark
    EMC classA
    Dimensions (L x B x H)539 mm x 210 mm x 415 mm
    21.2 inch x 8.3 inch x 16.3 inch
    Weight16.5 kg / 36.4 lbs
    StandardsIEC 60974-1, -3 and -10 CL.A
  • Technical data of the Picotig 200 puls AC/DC 8P TG

    Setting range for welding current3 A - 200 A
    Duty cycle 40 °C200 A / 35 %
    150 A / 60 %
    140 A / 100 %
    Open circuit voltage43 V
    Mains voltage (ex works)1 x 230 V
    Mains tolerances (ex works)-40 % up to +15 %
    Mains frequency50 Hz / 60 Hz
    Recommended generator power8.1 kVA
    Efficiency85 %
    Protection classificationIP23
    Test mark
    EMC classA
    Dimensions (L x B x H)539 mm x 210 mm x 415 mm
    21.2 inch x 8.3 inch x 16.3 inch
    Weight16.5 kg / 36.4 lbs
    StandardsIEC 60974-1, -3 and -10 CL.A
  • Overview of the EWM Picotig models

    This is what your Picotig can do.

    • Picotig 220 puls DC

      TIG

      • TIG standard DC
      • Average value pulsing
      • Automatic pulsing
      • HF start
      • Liftarc
      • spotArc®
      • spotmatic

      MMA

      • MMA standard
      • Average value pulsing
      • Cellulose electrodes
      • Antistick
      • Arcforce
      • Hot start

      Automatic pulsing
      HF start
      Touch starting
      Average value pulsing
      spotArc®
      spotmatic
      Standard DC
      Pulsed TIG welding DC

      allin-logo

      ewm garantie-logo

      ewm industrie40-logo

    • Picotig 200 MV puls TG

      TIG

      • TIG standard DC
      • Average value pulsing
      • HF start
      • Liftarc

      MMA

      • MMA standard
      • Average value pulsing
      • Antistick
      • Arcforce
      • Hot start

      HF start
      Touch starting
      Average value pulsing
      Standard DC
      Pulsed TIG welding DC

      allin-logo

      ewm garantie-logo

      ewm industrie40-logo

    • Picotig 200 puls AC/DC 5P TG

      TIG

      • TIG standard DC
      • Average value pulsing
      • HF start
      • Liftarc

      MMA

      • MMA standard
      • Average value pulsing
      • Antistick
      • Arcforce
      • Hot start

      HF start
      Touch starting
      Average value pulsing
      Standard DC
      Pulsed TIG welding DC

      allin-logo

      ewm garantie-logo

      ewm industrie40-logo

    • Picotig 200 puls AC/DC 8P TG

      TIG

      • TIG standard DC
      • Average value pulsing
      • HF start
      • Liftarc

      MMA

      • MMA standard
      • Average value pulsing
      • Antistick
      • Arcforce
      • Hot start

      HF start
      Touch starting
      Average value pulsing
      Standard DC
      Pulsed TIG welding DC

      allin-logo

      ewm garantie-logo

      ewm industrie40-logo

Picotig – Overview of controls

  • EASY HANDLING: THE COMFORT 3.0 MINI

    Picotig 220 puls

    Picotig 220 puls control Comfort 3.0 mini

    The Comfort 3.0 mini offers you a host of innovations, making your work easy as can be even in complex welding tasks. To ensure you have everything in view even with the welding helmet visor flipped down, the individual symbols of the control feature distinct backlighting.

    • Two large, easy-to-read 7-segment displays
    • Click wheel for convenient use with welder’s gloves
    • Reliable push-button operation
    • Direct access to all main functions
    • All parameters at a glance
    • Complete TIG sequence program
    • Access block to protect against unauthorised or accidental adjustment

    Welding torches: Versatility for every application.

    PM welding torch
    • The welding torch for every application

      Thanks to their well-balanced weight and ergonomic design, gas- and water-cooled welding torches from EWM are comfortable to grip and allow welders to work without fatigue. Extreme robustness and durability reduce costs for consumables and spare parts. Whatever your needs may be, you can find the perfect solution in the comprehensive range of EWM welding torches.

      Schweissbrenner_Picotig 220.png

    • TIG Retox XQ welding torch

      • Equipped with two torch triggers so the current can be reduced to a secondary current by tapping while welding
      • It’s possible to continuously increase (up function) or reduce (down function) the current while welding
      • Displays the welding current or the selected welding task (JOB number)
      • The grip lets the welder guide the torch safe and steadily
      • Standard or high-flex leather hose package (HFL: the first metre after the handle is covered with highly durable and soft nappa leather)

      EWM TIG Retox XQ welding torch

    • Spotarc welding torch

      Pinpoint precision – the solution for spot welding fillet welds, edge welds and flat welds

      EWM Spotarc welding torch

    • Flexible connection

      • The standard 5-pole torch connection is now compatible with EWM X technology
      • You can connect digital EWM multi-function torches with display and remote-control functions in addition to conventional welding torches

      EWM TIG Retox XQ welding torch

    Picotig – Accessories

    Needs-oriented and versatile.
    You can enhance the Picotig 220 puls with a comprehensive range of accessories precisely oriented to your needs. From the practical carrying strap to the foot-operated remote control to the dirt filter – you decide what your EWM welding machine needs to do.

    Picotig accessories

    • Ideal for mobile use and frequently changing locations

      ON TG
    • Transport cart (2 rollers) for moving a power source and one shielding gas cylinder

      Trolly 35-1
    • Gas cooled TIG welding torch with a flexible torch neck and a highly flexible hose package

      Double push-button

      Duty cycle DC-: 200 A / 35 %

      TIG 200F GRIP GD HFL
    • Remote control for MMA welding

      RTA PWS2
    • Dirt filter for air inletON Filter TG.12
    • Foot-operated remote control, start/stop

      RTF-X TIG



      Picotig machine documentation
